Amphibious multipurpose dredger
One versatile machine for all shallow water work
One versatile machine for all shallow water applications
Watermaster amphibious multipurpose machine excels alone in the tasks that are conventionally handled with multiple separate machines.
With its versatile selection of quickly changeable attachments, the Watermaster can do all shallow water work from dry ground up to the depth of 20 feet.
Watermaster offers superior mobility
Transport, launch, and operate the dredger with ease with a hydraulically pivoting propeller at a cruising speed of 4 knots.
.
01 Transport
Transport the dredger on a standard trailer.
Watermaster is transported as a complete unit, so there are no set-up times when arriving at the site.
02 Launch
Launch the dredger without set-up times, cranes and tugboats.
Watermaster is amphibious and can walk independently in and out of water without crane assistance.
03 Travel to worksite
Operate the dredger without winches, wire cables and assisting vessels.
Watermaster has its own propulsion system so it can get to the site independently without the help of tugboats.
04 Operate
Watermaster has four stabilizers enabling steady and accurate anchoring and operation.
AMD 5000
Amphibious Multipurpose Dredger
Standard Equipment
Watermaster Hull with Four Hydraulic Stabilizers and Four Side Pontoons
Cat C7.1 Tier 4 Diesel Engine for Hydraulics and Propulsion System
Excavator Arm with Central Pressure Greasing System
Watermaster Cutter Pump
3/4 Yard Excavator Bucket
Climate Controlled Cabin
Two Weeks On-Site Training
Specifications
Engine
Caterpillar C7.1, turbo charged, Tier 4, 6-cylinder diesel engine 275 bhp tier 4 compliant
Air-water radiator cooled
Flywheel power at 2100 rpm, 275 bph
Two fuel tanks inside the hull with a total capacity of 316 gallons
Electric system 24 V
Batteries 2 x 170 Ah
Electric refueling pump
Hydraulics
axial piston pump (1) for dredging and propeller
operating pressure 5000 psi
axial piston pump (1) for excavator and stabilizers
operating pressure 3300 psi
Excavator
swingrange 180°
breakout force bucket cylinder 18,650 lbf
digging force from arm cylinder 10,560 lbf
lifting capacity at max. reach 5,500 lbf
Hull
one piece, 7 watertight compartments
protective skid bars on bottom
corrosion resistant paint inside and out
mast, signal lights for dredging and navigation
Cabin
modern FOPS certified cabin with excellent visibility
additional seat for instructor
10 work lights
Anchoring
two front hydraulic outriggers 16.3 ft depth,
two hydraulic rear spuds 21.75 ft depth
no vessels, cables or winches needed to work or anchor
Mobility
self loading and unloading on/off lowboy trailer
moves independently in and out of water
amphibious in all work functions
transport length with boom 52 ft, 10.75 ft, height 10.23 ft
Certified quality
For quality assurance each Watermaster is registered by the US Coast Guard National Vessel Documentation Center (NVDC).
Watermaster’s reliability is demonstrated through over 3 decades of engineering, testing and continuous improvement in design and manufacturing.
Transport dimensions and weight
Transport length without boom 34’6”
Transport length with boom 17,00 m
Transport width: 3,30 m
Transport height: 3,15 m
Transport weight ca 21.5 tons
Get in touch
If you would like to know more about the Watermaster AMD 5000 and if it can help with your project, feel free to get in touch. Click the button below to send us an email.
